ARB Air Locker Manifold Kit

Designed to work seamlessly with ARB’s twin motor on-board compressors, the Air Locker Manifold Kit enables easy installation of Air Locker solenoids to an air source such as a compressor or regulated gas bottle.

With a working pressure of 150PSI (1030kPa), the manifold kit incorporates multiple ports for use with ARB’s pump up kit, as well as mounting brackets and a Teflon stainless steel braided hose designed to cool air supply for tyre inflation.

The Air Locker Manifold Kit includes:

• Manifold body with mounting bracket

• 2 x 1/8”BSPP ports for installation of up to 2 x Air Locker solenoids

• 2 x 1/4” NPT ports, one to be used as an input and the second could be used for installation of a pump up kit
(ARB #171302)

• 1 x high temperature resistant Teflon stainless steel braided hose with heavy duty JIC4 fittings

• 2 x JIC4 - 1/4NPT nipples to connect the included hose to the compressor outlet and manifold kit input

• 2 x M6 hex head bolt and nylon lock-nuts for securing the manifold kit
